Fastening device УП.П(1)(50) is indispensable for FOCLs build applications. Is used for suspending two parallel self-supporting ADSSs (type 8 FOCs, carrying ropes) at poles of overhead power lines (OPL). Support cross-section shape: rectangular.
Supplier and manufacturer: OOO Trading House MSK.
Availability: Moscow, Saint Petersburg (warehouses).
УП.П(1)(50) price: on request from the managers.
Delivery term: 1-3 days (after payment receipt).
Delivery set of device УП.П(1)(50)
The fastening device УП.П(1)(50) consists of:
- cross-arm (angle bar 50×50) — 1 pc.
- stop (angle bar 50×50) — 1 pc.
- Stud — 2 pcs.
- nut — 8 pcs.
Diagram symbols:
А - support overall dimension at cross-arm end, mm
Б — support overall dimension at stud end, mm.
Vertical load on the assembly during operation — > 5 kN.
Product attachment method
The assembly is attached to CB type OPLs of rectangular cross section using studs included to the product scope. Attachment height is specified in the project documentation. For attachment, ADSSs use spiral (hold) clamps ПСО, and type 8 cables use clamps ЗП.
Sales of holding assemblies УП.П(1)(50)
Our company produces and supplies devices and components for fastening of and suspend FOCs or FOC carrying ropes. Hold device УП.П(1)(50) is sold and shipped from our stock at warehouses in the Northwest and Central regions. Delivery to Saint Petersburg and Moscow transport terminals at our expense.
