Anchor clamp VS-3

Manufacturer code: VS-3

Product Weight ±10%, kg 0.11

Dimensions (L × W × H), mm 227х70х34

Working Load, kN 2.5

Loop Length, mm 160

Distance between supports, m ≤ 50

Clamped Cable Diameter, mm 3...7

Housing Length, mm 50

Loop Rod Diameter, mm 5

Description

Anchor clamp VS-3 is used to firmly attach Ø 3 mm to 7 mm FTTH drop cables. The clamp consists of a frame, two wedges and a loop of galvanized steel rod. The frame and wedges are made of high-strength UV-resistant polymer. The loop may be separated for easy hooking.
