Anchor clamp VS-15

Manufacturer code: VS-15-4

Product Weight ±10%, kg 0.05

Dimensions (L × W × H), mm 195×27×22

Working Load, kN 0.6

Distance between supports, m 30 ... 40

Hook Rod Diameter, mm 5

Clamped Cable Diameter, mm 5

Housing Length, mm 60

Clamped Flat Cable Size, mm 4х7

Hook Length, mm 125

Housing/Wedge Material High-Strength UV-Resistant Polymer

Hook Material Steel Rod

Description

Anchor clamp VS-15 is used for up to Ø5 mm round self-supporting FOCs and up to 4×7 mm flat FTTH cables.

H15 clamp consists of a frost-resistant plastic frame, polymer wedges and galvanized steel hook.
The bearing component requires no separation or cleaning to be attached during installation. No tools are necessary.
The cable sheath is not damaged when using these anchor clamps.
Max. span between attachment points is 30 to 40 m depending on cable design.
A distinctive feature of this clamp is that under increased load (icing, falling branches on the cable, hurricane winds) the clamp breaks without damaging the FOC, preventing eventually line disruption.
