3D model of Hold fastening device УКПТУ-01
Technical characteristics:
| Description |
Size range of support profile, mm
|
Max. working load Р1, kN |
Max. working load at 45° to the device plane P2, kN |
Overall dimensions A×B×C, mm |
Weight, kg |
| УКПТУ-01 |
63-125 |
70 |
25 |
177×138×270 |
2.2 |
| УКПТУ-02 |
140-200 |
70 |
25 |
250×138×336
|
2.7 |
Working temperature range -60 to +40°С.
Package contents
The band clamp supply package includes:
- bracket – 1 pc.;
- hook – 2 pcs.;
- hold-down pad – 1 pc.;
- bolt M12 – 1pcs.; г
- nut M12 – 5 pcs.;
- spring washer – 1 pc.;
- flat washer – 1pcs.;
- product datasheet – 1 pc.
Transportation and storage conditions
The manufacturer guarantees that main characteristics will not change if the consumer observes transportation and storage conditions of group 3 GOST 15150.
The product may be transported by all modes of transport according to the transportation rules applicable to this transport type.
Operational life
Device operational life — 25 years.
The actual service life is not limited to the above, but is determined by the product technical condition.
Warranty obligations
Warranty period of device УКПТУ-01(-02) is 36 months from the date of sale, subject to consumer compliance with the rules of transportation, storage and operation.
Fig. 1 – Hold fastening device УКПТУ:
1 – bracket; 2 – hook; 3 – hold-down pad; 4 – bolt M12; 5 – nut M12; 6 – spring washer M12; 7 – flat washer M12.
