The fastening device is protected with zinc coating
See Fig. for design of УКС-Н:
Universal fastening device УКС-Н
Technical characteristics:
-
Max. working load: Р = 10 kN (device strength without accounting for anchor bolts strength).
-
Weight (without anchor bolts) 0.53 kg.
-
Working temperature range -60 to +40°С.
Package contents
The band clamp supply package includes:
-
Device УКС-Н assy;
-
Product datasheet.
Anchor bolts are not included infor fastening ofing device supply package. When selecting anchor bolts, wall characteristics and embedment required strength need consideration
Transportation and storage conditions
The manufacturer guarantees that main characteristics will not change if the consumer observes transportation and storage conditions of group 3 GOST 15150.
The product may be transported by all modes of transport according to the transportation rules applicable to this transport type.
Operational life
Device operational life — 25 years.
The actual service life is not limited to the above, but is determined by the product technical condition.
Warranty period of device УКС-Н is 36 months from the date of sale, subject to consumer compliance with the rules of transportation, storage and operation.
