See Fig. for design of УН:
Universal fastening device УН
Technical characteristics:
|
Characteristics
|
Denotation
|
|
Max. working load
|
12 kN
|
|
Weight
|
6.1 kg
|
|
Working temperature range
|
-60 to +40°С
|
|
Support size range
|
310- 410 mm.
|
3D model of Tension fastening device УН
Package contents
The band clamp supply package includes:
-
Device УН assy;
-
datasheet.
Transportation and storage conditions
The manufacturer guarantees that main characteristics will not change if the consumer observes transportation and storage conditions of group 3 GOST 15150.
The product may be transported by all modes of transport according to the transportation rules applicable to this transport type.
Operational life
Device operational life — 25 years.
The actual service life is not limited to the above, but is determined by the product technical condition.
