See Fig. 1 for design of УК-Н-3К:
Fig. 1: Tension fastening device УК-Н-3К
Technical characteristics:
-
Max. working tensile load at angle Р = 40 kN;
-
Max. working load at eye Р1 = 20 kN;
-
Weight – 4.5 kg;
-
Stud length range – 150 to 255 mm;
-
Distance between studs — 193 to 269 мм;
Package contents
The band clamp supply package includes:
-
Product datasheet — 1 pc.
-
Device УК-Н-3К assy (rest – 1 pc., tension cross-arm – 1 pc., nut М12 – 8 pcs., stud – 2 pcs., washer – 4pcs.).
Transportation and storage conditions
The manufacturer guarantees that main characteristics will not change if the consumer observes transportation and storage conditions of group 3 GOST 15150.
The product may be transported by all modes of transport according to the transportation rules applicable to this transport type.
Operational life
Device operational life — 25 years.
The actual service life is not limited to the above, but is determined by the product technical condition.
