See Fig. 1 for design of УК-Н-2К:
Fig. 1: Tension fastening device УК-Н-2К
Technical characteristics:
-
Max. working load at hooks – Р=13 kN;
-
Max. working load at eye – Р=20 kN;
-
Weight – 4.4 kg;
-
Distance of stop to tension cross-arm — 150 to 255 mm;
-
Center distance between studs — 215 to 250 mm;
-
Working temperature range -60 to +40°С.
3D model of product
Package contents
The band clamp supply package includes:
-
Product datasheet — 1 pc.
-
Device УК-Н-2К assy (rest – 1 pc., tension cross-arm – 1 pc., nut М12 – 8 pcs., stud – 2 pcs.)
Transportation and storage conditions
The manufacturer guarantees that main characteristics will not change if the consumer observes transportation and storage conditions of group 3 GOST 15150.
The product may be transported by all modes of transport according to the transportation rules applicable to this transport type.
Operational life
Device operational life — 25 years.
The actual service life is not limited to the above, but is determined by the product technical condition.
