See Fig. 1 for design of УК-П-К:
Fig. 1: Hold fastening device УК-П-К
Technical characteristics:
-
Max. vertical working load – Р=2 kN;
-
Weight – 3.7 kg;
-
Distance of stop to hold cross-arm 150 to 255 mm;
-
Center distance between studs — 225 to 261 mm;
-
Working temperature range -60 to +40°С.
Package contents
The band clamp supply package includes:
-
Product datasheet — 1 pc.
-
Device УК-П-К assy (rest – 1 pc., support cross-arm – 1 pc., nut М12 – 8 pcs., stud – 2 pcs.)
Transportation and storage conditions
The manufacturer guarantees that main characteristics will not change if the consumer observes transportation and storage conditions of group 3 GOST 15150.
The product may be transported by all modes of transport according to the transportation rules applicable to this transport type.
Operational life
Device operational life — 25 years.
The actual service life is not limited to the above, but is determined by the product technical condition.
