Hold device УКПУ-01

The fastening device is protected with zinc coating complying with environment category C3.

See Fig. 1 for design of УКПУ-01:

Fig. 1: Hold fastening device УКПУ-01.

1 — frame; 2 — rod; 3 – brace; 4 — hook; 5 – bolt M16×40;

6 – nut M16; 7 – washer; 8 – spring washer.

Version УКПУ-02 – specular reflection.

Technical characteristics:

• Max. vertical working load — Р_в=17 kN

• Height – 680 mm

• Length 515 mm

• Weight — 11.7 kg

• Working temperature range -60 to +40°С.

Package contents

The band clamp supply package includes:

• Device УКПУ assy;

• Product datasheet — 1 pc.

Transportation and storage conditions

The manufacturer guarantees that main characteristics will not change if the consumer observes transportation and storage conditions of group 3 GOST 15150. The product may be transported by all modes of transport according to the transportation rules applicable to this transport type.

Operational life

Device operational life — 25 years.

The actual service life is not limited to the above, but is determined by the product technical condition.
