See Fig. 1 for design of УКУШ:
Fig. 1 – Universal fastening device УКУШ: 1 – Flange; 2 – Plate; 3 – Bolt M16; 4 – Nut M16; 5 – Washer 16. 2.
Technical characteristics:
|
Description
|
Channel gage acc. to GOST 8140-97, mm
|
Max. working load P1, kN
|
Max. working load at 45° to the device plane P2, kN
|
Overall dimensions L×W×H, mm
|
Weight, kg
|
|
УКУШ
|
6.5;8;10
|
70
|
25
|
120×116×275
|
3.6
|
Working temperature range -60 to +40°С.
Transportation and storage conditions
The manufacturer guarantees that main characteristics will not change if the consumer observes transportation and storage conditions of group 3 GOST 15150.
Operational life
Device operational life — 25 years.
The actual service life is not limited to the above, but is determined by the product technical condition.
